i have two saturn systems. one is the model1 and the other is model 2. i opened up my saturn model2 today, and saw that there is a spot for a L.E.D. all you would have to do is get one from radioshak and solder it in.

it would be a lot cheaper then getting a modbord. has anyone tried this? im going to try it tomorrow. ill let you all know how it goes. and ill try to take pics. this would solve alot of swap-trick problems. you would probably have to drill a small hole so you can see the light for the correct timing. peace out


Curtis

Member
Joined
Sep 26, 2001
Messages
2,594
Points
36
Age
36
Website
Visit site
Are you suggesting that this LED will act in the same manner as the drive access LED on the model 1? I think thats a long shot to say the least... Still no one has tried this (for good reason, I suspect), but have fun anyway...

Personally, I don't think the swap trick is that hard, not hard enough that a little flashing light would make it any easier, anyway...


norberto

New Member
Joined
Jan 6, 2002
Messages
39
Points
6
Website
Visit site
im hoping it will act in the same manner! i dont see why not. you are right about the swap method is not that tough, but many people find it a pain. people with model 2 saturns anyway. also alot of people keep their saturns cases open for that same reason(to watch the laser move easier). everybody can finally put their covers back on!

(Edited by norberto at 4:28 am on Jan. 8, 2002)

(Edited by norberto at 4:29 am on Jan. 8, 2002)


mal

Member
Joined
May 14, 2001
Messages
7,123
Points
36
Age
44
Website
Visit site
I think norberto, you might be right about the space on the controller PCB. It makes sense that it's for the CD access light. I think it's only on older Model 2 Saturns though.

How were you thinking of mounting the LED?

It's a long way from the PCB to the top of the case.


IceDigger

Founder
Staff member
Joined
Apr 16, 2001
Messages
5,516
Points
38
Age
39
Location
USA
Website
www.segaxtreme.net
two wires and a 3 mm (or 5 mm, depending on the led size) hole, some hotglue to keep it in place.

it won't damage anything if it doesn't work. just remember the LED might not work the first time cause the contacts are the wrong way, if so, just turn it around.


MasterAkumaMatata

Staff member
Joined
Apr 18, 2001
Messages
3,300
Points
36
Location
Akuma Island
Website
superakuma5k.homestead.com
Quote: from Curtis on 3:48 am on Jan. 8, 2002

Are you suggesting that this LED will act in the same manner as the drive access LED on the model 1? I think thats a long shot to say the least... Still no one has tried this (for good reason, I suspect), but have fun anyway...

Personally, I don't think the swap trick is that hard, not hard enough that a little flashing light would make it any easier, anyway...
I feel the same way. I don't use the LED on my old model 1 Saturn to do the swap trick. I use the movement of the lens as my cue. Now that I have a modded model 2 Saturn, there's no need for me to swap anymore, unless I'm in the mood for a little challenge. ;)


SkankinMonkey

Member
Joined
Apr 16, 2001
Messages
1,594
Points
36
Age
37
Website
Visit site
You still have to remember that the timing is different on the model 2 from tthe model 1, so even if the lights do work, it won't be the same as the model 1.


norberto

New Member
Joined
Jan 6, 2002
Messages
39
Points
6
Website
Visit site
hey whats up? im about to go to radioshack in about an hour. i was also thinking about getting different color l.e.d.'s. ill be taking pics also. i was thinking about drilling a small hole like where the power led is by the reset button, and using that little clear plastic peice from the green power led, and putting it on the other side. there is a spot for it. how do i post pics?


MasterAkumaMatata

Staff member
Joined
Apr 18, 2001
Messages
3,300
Points
36
Location
Akuma Island
Website
superakuma5k.homestead.com
hey whats up? im about to go to radioshack in about an hour. i was also thinking about getting different color l.e.d.'s. ill be taking pics also. i was thinking about drilling a small hole like where the power led is by the reset button, and using that little clear plastic peice from the green power led, and putting it on the other side. there is a spot for it. how do i post pics?
Like this:

<font color=white>[</font>img]URL of pic here<font color=white>[</font>/img]

For example:

<font color=white>[</font>img]http://superakuma5k.homestead.com/files....]<font color=white>[</font>/img]

(Edited by MasterAkumaMatata at 2:51 pm on Jan. 8, 2002)


IceDigger

Founder
Staff member
Joined
Apr 16, 2001
Messages
5,516
Points
38
Age
39
Location
USA
Website
www.segaxtreme.net
just stick the LED straight through the hole, much easier.

you can use the
tags to post a pic on some webspace you upload them to. if the pics are large (kb-wise), it's better to post a link.


norberto

New Member
Joined
Jan 6, 2002
Messages
39
Points
6
Website
Visit site
im about to test it out!!!!!!!!!1 cross those fingers!

two more pics with the red led in, and the plastic light extender thingie switched to the other side.





norberto

New Member
Joined
Jan 6, 2002
Messages
39
Points
6
Website
Visit site
well of course it diddnt want to work at all! (it worked, but the led did not come on for accessing.) oh well at least i tried. i switched the controller board to my model 1 and it works fine. sega is smarter than I. oh well, at least i got some cool led's for my saturn now. not a total loss i guess. some times the pics come up. here are all the pics i took including the blue power led, and the green led access light! copy and paste the link!

http://www.geocities.com/tandynor/page5.html

(Edited by norberto at 6:58 pm on Jan. 8, 2002)


Fabrizo

New Member
Joined
Oct 3, 2001
Messages
992
Points
16
Age
34
Website
Visit site
I think those new power and access lights look sweet! I think ill see if I can do the same with my model 1 saturn, its falling apart anyways from all the tampering ive done on it.
