Is it possible to configure Pseudo Saturn or PS Kai to behave like a stock Saturn (no splash screens/menus etc.) on boot when booting retail discs?
It's not possible on Pseudo Saturn, and I don't plan to add such feature on Pseudo Saturn Kai.

Details : my vision for Pseudo Saturn is to make it more than "a hack that loads CD-R copies of original games". So far I added backup memory cartridge feature to it (*) and next release will allow usage of cheat codes. Theses two features can be used on both CD-R and original CDs.
I did my best to remove usage of menus regarding backup memory cartridge feature (so far Pseudo Saturn Kai was prompting if it should be enabled or not, but next release will decide that automatically), but this is not possible to do that for cheat codes since user may want to choose which cheat to enable.

Additionally, why aren't you using a modchip your Saturn ? This can load both original and CD-R games silently as on a stock Saturn hence may be more suitable to your needs.

(*) This is available for Gamer's Cartridge only. I don't plan to add this for flash ROM based solutions such as Action Replay cartridges.


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
Pseudo Saturn Kai v6.272 (RC1) will finish to be uploaded in about 48 minutes :)
Before putting everything in the wild, it would be cool if some volunteers could test it on their Saturns : if interested, please contact me by PM.

When contacting, please inform me about which hardware you plan to use for testing.
Examples :
- Action Replay (or similar) cartridge
- Rhea/Phoebe ODE
- Modded Saturn
- Official memory cartridge and/or Saturn Floppy Disk

If you have the hardware but no time for testing, then please don't contact me and patiently wait for Pseudo Saturn Kai to be publicly released.


vbt

Staff member
Joined
Dec 16, 2001
Messages
5,185
Points
63
Age
42
hey I was ready for testing too! you forgot to mention what was new :

2018/12/23 (Pseudo Saturn Kai, V6.272) :
- Finished credits page for Pseudo Saturn Kai, Save Data Manager and DZ2SGM.
- Added simple support for 3D pad analog arrow : so far 3D pad was supported,
but only status of digital arrow was considered.
Note : debug menus directly embedded in ROM for Virtual Memory Cartridge and
cheat codes (example : BSOD screen, etc) are kept as-is so only
digital arrow is supported there.
Same limitation applies to standalone firmware flasher too.
- Added retry access to CD-ROM (up to 5 times) when current access failed.

2018/12/06 (Pseudo Saturn Kai, V6.262) :
- In ODE settings menu, fixed update condition regarding settings not requiring
to reload disc image list.
- In Save Data Manager, added the ability to return to main menu from flasher.
- In flasher utilities, added warning message when trying to flash firmware
other than Pseudo Saturn Kai full version on SST39SF040 chips used on
USB dev cart or Gamer's Cartridge.

2018/12/03 (Pseudo Saturn Kai, V6.261) :
- Fixed Japanese character display in menus.
This was a regression from V6.257, caused by addition of font cache in menu.
- Fixed display of strings larger than display area during "condensed" menu.

2018/11/28 (Pseudo Saturn Kai, V6.260) :
- In ODE image selection menu, added images list ascending/descending settings.
- In ODE image selection menu, added text justify (left or center) settings.
- In ODE image selection menu, added setting for changing color theme.
- In ODE settings menu, added option to enable compatibility reporter.

2018/11/26 (Pseudo Saturn Kai, V6.257) :
- Added cache support for font used in menu items.
Tested on real HW, and it seems to improve a little display performances
when "condensed" menu is used.
- In Dezaemon 2 SGM3, changed entry selection menu to "condensed" type.
- In Dezaemon 2 SGM3, changed initial zoom factor in screenshots gallery
from "all" to "1:1".

2018/10/02 (Pseudo Saturn Kai, V6.252) :
- Added "condensed" (no border, and using proportional font) menu type.
It is currently used in ODE image selection menu as well as in game and cheat
code selection menus.
- In ODE image settings menu, added a setting to toggle between "monospace"
and "proportional" image selection menu type.
- In ODE image selection menu, fixed sorting of multi-CD (with same release
date) when sorting by release date or folder ID.
- In ODE image selection menu, added update of setting to internal backup
memory when toggling sort settings with Y button.


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
hey I was ready for testing too! you forgot to mention what was new :
I didn't forgot to mention what's new : I was just lacking of time to summarize informations from Pseudo Saturn Kai behemoth changelog :)
(In fact, I still need to announce the release on my blog, but I'm too sleepy to do it now)

Please find below a digest changelog. This is just a summary, so people interested in all the changelog can find in in Pseudo Saturn Kai readme.


Added automatic game loader
So far in Pseudo Saturn Kai 6.074, user had to choose which game loader to choose before starting a game, but this is now done automatically on Pseudo Saturn Kai side.
There's no magic around this feature : it just uses a list of games not compatible with CWX loader, and decides accordingly :)


Added cheat codes feature
That's a big addition for this release. Its development spans around June 2017 to Spring 2018.
The main features for cheat codes are :
→ Built-in : don't need to manually enter the cheat codes
→ User friendly : just push X button when booting a game, and then select the cheat(s) to enable.


Added disc images menu for Rhea/Phoebe ODEs
Back in 2015, I added a stub of alternate rmenu to Pseudo Saturn Kai, but didn't had the technical information regarding Rhea/Phoebe API so the feature was disabled in its unfinished state.
And this summer, an enthusiast friend helped a lot to get this technical information, so that I could finally finish this feature :]
Development of this feature was an occasion to bring usage of proportional font in image selection menu, thus showing more information on a single screen. Base of menu module was developed around 2010 without any consideration for proportional font, so development of this side feature was a nightmare, but I don't regret for having done it now it is finished :)

Here is what it looks like :



Added Dezaemon 2 Save Game Manager 3
Dezaemon 2 is a shooting game maker application for Saturn. And Save Game Manager is a collection of user games for Dezaemon 2.
By the past, there were two volumes released by Madroms : SGM1 in 2007 and SGM2 in 2008.
And 10 years after that, SGM3 is released and contains some new user games as well as all the games from SGM1 and SGM3 : one SGM to rule them all :D

Special thanks to Dezaemon DB for gathering a community around Dezaemon 2, and dumping the user games :)


Added a stylish logo for Pseudo Saturn Kai
That's maybe a detail, but that was really missing from a long time !
Special thanks to Alien^PDX for the logo, and CyberWarriorX for putting me in touch with him :)

Here is what it looks like :



Added in-game connectivity for USB dev cart
This uses cheat codes routine, hence requires at least a valid master code to be set.
It can do USB connectivity while doing transfer with PC, but that's a bit slow (because of unoptimized C running from cartridge ROM), and consequently may cause glitches on some games.
As a countermeasure, there is another mode who does only USB connectivity (hence no cheat codes) but does it fast since the code for it is written directly in assembly and running in RAM.
That may be cool for game hacking, or looking for new cheat codes ... but I still need to add a proper cheat codes finder feature on SatLink before looking for cheat codes on my favorite games :)

Here is a video about this feature : (Radiant Silvergun was one of the very first games to work correctly with Pseudo Saturn Kai cheat codes :) )

I stopped USB dev cart support, so this feature is disabled and software on PC side won't be released.


Added Virtual Memory Cartridge support via USB dev cart
This is similar to "Virtual Memory Cartridge" used in Gamer's Cartridge, but access save data files on PC via USB dev cart instead of SD card.
That's convenient for save data hacking, or testing several saves, but for normal use then using SD card is (in my opinion) a better choice.
As a consequence, full firmware can now be installed on USB dev cart. But cartridges not using SST39SF040 flash chips are not supported (because there's not enough room in flash ROM) and in that case only lite firmware can be installed.

A video about this feature is available here :
I stopped USB dev cart support, so this feature is disabled and software on PC side won't be released.


Fixed support for 3D pad
In previous version, using 3D pad would sometimes cause an emergency exit to multiplayer screen when touching analog buttons. This is now fixed, and additionally supports input from analog buttons.
Pseudo Saturn Kai is not a 3D game, so the interest of using analog buttons is a bit questionable, but at least it is supported now :)


And the most voluminous change is ... :
Fixed many bugs everywhere, added other bugs here and there
Everything should work now. Trust me, I'm an engineer :)

Last edited:

cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
Hi Madroms, long time no see on Segaxtreme forums :)

There's no problem to mirror DZ2SGM3 archive on satakore.com, as long as :
- Archive contents are not altered
- There's a link to my homepage and to Dezaemon DB's too
(That's basically to prevent SMG3 from being re-appropriated and/or repacked in a commercial project)

Thank you very much for your work on SGM1 and SGM2 ! The tradition of releasing SGMs on Christmas helped a lot in making this huge release becoming a reality :)


Madroms

New Member
Joined
Jul 29, 2001
Messages
148
Points
18
Website
www.satakore.com
Hi Madroms, long time no see on Segaxtreme forums :)

There's no problem to mirror DZ2SGM3 archive on satakore.com, as long as :
- Archive contents are not altered
- There's a link to my homepage and to Dezaemon DB's too
(That's basically to prevent SMG3 from being re-appropriated and/or repacked in a commercial project)
Yes, no problem. It is to add the link on the post I made on the homepage, so with all the necessary links to your pages and Dezaemon community.


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
keep up the great work ...:)
I still got nothing done or even started ...:(
Hurry up, or I will finish your projects before you ^^

Yes, no problem. It is to add the link on the post I made on the homepage, so with all the necessary links to your pages and Dezaemon community.
OK, so everything is all right then. BTW, thank you for putting links to my homepage and Dezaemon DB before I told theses were needed :)


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
Just to announce that I updated Pseudo Saturn Kai and Dezaemon 2 Save Game Manager to stable versions on my homepage :)

After the public release at the beginning of this week (v6.272), I had some troubles with 1MB/4MB expansion RAM not working on a beta tester's cartridge, and couldn't clearly find what's wrong with this. As debugging cartridge expansion RAM things takes time (and that I want to take a break during summer vacations), I temporarily removed things related to expansion RAM so that it shouldn't cause problems now :D
I tested this latest firmware on my good old Action Replay and a game requiring expansion RAM (KOF 96), and do confirm everything is working fine now.

Cartridge RAM self test feature will be added back in a future revision, but current one (v6.274) shall remain the latest stable version for a while. So if possible please update to v6.274 if you are using the "didn't lasted long v6.272". Sorry for the double effort and happy playing :)


@Madroms : I caught the occasion to make Dezaemon 2 Save Game Manager menu showing directly on startup (so far it was required to manually enter it from Save Data Manager main menu), so please mirror this version rather than the one released at the beginning of the week.


To make things clear with version numbers :
v6.272 : initial public release with cheat codes feature, etc.
v6.273 : tried to fix expansion RAM initialization, but still had problems reported about it.
v6.274 : removed things related to expansion RAM. ← should be a stable release for a while


mfncl

New Member
Joined
Jan 3, 2019
Messages
2
Points
1
Age
34
Some (not all) revisions of Japanese grey Saturns don't work correctly with JHL loader, so it can't guarantee you can play this game on your Saturn.
I recently tried to get PDS working with CWX loader ... and didn't undestood what need to be fixed :D I really want to fix compatibility for the 4~5 picky games not working with CWX loader, so shall give another try in the future.
Just getting into Saturn and picked up a grey Japanese model 1 and a ready flashed Pseudo Saturn. Updated to the latest 2018-12 FW, and have to say really nice work on the loader, the GUI and UI/UX is awesome.
All games I've tried are working, except for Panzer Dragoon Saga.

Sorry for bumping an old post, but wanted to see if any further work was planned on getting the small number of games working with the CWX loader that includes PDS? Same issue as a couple of pages back, have a grey model 1 JPN Saturn that has the compatibility issues with the JHL loader (side note: I assume the JHL loader is no longer maintained, thus the efforts to get the games working with CWX).
If not, I guess a mod chip would be the next best option (beyond buying a new console, which I don't really want to do since I just got this one :)).
Out of interest, what are the other 4 games that won't work with CWX loader (patched or otherwise)?


mfncl

New Member
Joined
Jan 3, 2019
Messages
2
Points
1
Age
34
I decided to return my grey Saturn in favor of a white model 2.. it's a lot easier for me to swap my Saturn out than it is for you to look into the model 1 compatibility issues, so definitely better this way.
Doesn't look like there are all that many users out there running into these compatibility issues so I'm sure there are a lot of other PSK priorities that are more worth your time :)


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
@cafe-alpha Thanks for all your hard work! This is amazing <3
You're welcome ! Have fun and happy playing :)


Just getting into Saturn and picked up a grey Japanese model 1 and a ready flashed Pseudo Saturn. Updated to the latest 2018-12 FW, and have to say really nice work on the loader, the GUI and UI/UX is awesome.
Thank you ! Improving UI and UX wasn't an easy job. As it is finished now I'm glad of the result, but really won't re-do that once more :D

Sorry for bumping an old post, but wanted to see if any further work was planned on getting the small number of games working with the CWX loader that includes PDS? Same issue as a couple of pages back, have a grey model 1 JPN Saturn that has the compatibility issues with the JHL loader (side note: I assume the JHL loader is no longer maintained, thus the efforts to get the games working with CWX).
If not, I guess a mod chip would be the next best option (beyond buying a new console, which I don't really want to do since I just got this one :)).

(snip)

I decided to return my grey Saturn in favor of a white model 2.. it's a lot easier for me to swap my Saturn out than it is for you to look into the model 1 compatibility issues, so definitely better this way.
Doesn't look like there are all that many users out there running into these compatibility issues so I'm sure there are a lot of other PSK priorities that are more worth your time :)
I don't plan to plan improve JHL loader for Japanese grey Saturns in a near future : it's not that I don't want to do it, but it's more complex than CWX loader and concerns few games on few Saturn models too. As you indicated, there are other things that takes priority in development.


Out of interest, what are the other 4 games that won't work with CWX loader (patched or otherwise)?
Hrm ... I don't remember exactly :D I think Skeleton Warriors isn't working with CWX loader too.
Problematic games are listed in "Games Requiring Patching" section of Pseudo Saturn Kai readme , but this is the list of games requiring patching, which is larger than the list of games not working with CWX loader even if patched.


drspod

New Member
Joined
Jan 30, 2019
Messages
1
Points
1
Sorry if this is the wrong place to ask this question as I'm new to this forum.

Is there a way to region patch the pskai_alternate_flasher.iso so that it can be booted using a regular disk-swap trick without having a functioning region-free cartridge (ie. ARP) installed?

The reason I ask is that I may have bricked my ARP with a failed flash, and I am wondering why I cannot just load up the flasher again and rewrite the firmware. I am assuming that the reason I cannot use a disk-swap trick to load the flasher currently is that it relies on the working cartridge to remove the region restriction. If I could create a flasher ISO with PAL region then I could load it with a regular disk-swap.

Thanks very much for any help or advice that anyone is able to give.

Update: I managed to rescue the bricked AR with a new AR successfully flashed with PSKai. As far as I can tell, the flasher ISO has no region restriction so I'm not sure why I could not boot it again after failing the first time, as it shouldn't need a working region-free cartridge to boot it.

I was able to boot the flasher using PSKai and then just swap the cartridges to flash the bricked cartridge. I have read that this risks damage to either the cartridge or the Saturn, but I did not experience any such issue, so that is at least one anecdotal data point that it can be done!

Last edited:

cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
Sorry for the delay ! I do confirm that Pseudo Saturn Kai flasher utility isn't limited to a specific region.
And, sometimes a bricked cartridge may prevent from loading the flasher utility so that it is necessary to insert the cartridge loosely to make Saturn BIOS ignoring it, and then adjusting its position in its slot when flasher utility is running.

Cartridge and/or Saturn may be bricked after an hotswap : this doesn't happens every time but I can't guarantee it won't be harmful a day or another. Personally, I damaged one Saturn because of that (I accidentally removed a cartridge while it was powered on), and because of that it is no longer able to flash any cartridge.
For this reason I don't promote the hotswap method everywhere and prefer the "insert loosely, then adjust in the slot" way of de-bricking cartridge instead.

Sorry if this is the wrong place to ask this question as I'm new to this forum.
This is the right place to ask or discuss about Pseudo Saturn Kai :)


the Goat

New Member
Joined
Feb 3, 2019
Messages
2
Points
1
Location
Burlington Vermont
I'm trying to use the Rhea ODE menu feature on Pseudo Saturn Kai release 20181227 installed on an action replay. But the Pseudo Saturn UI just locks up instead of showing the ODE menu. I have a genuine Rhea ODE and it is updated to the latest firmware (3.9.0). The SD card has three games on it. All three of the games work with the Rhea ODE just fine.

What am I doing wrong?


cafe-alpha

Member
Joined
Dec 13, 2005
Messages
495
Points
43
Location
Japan
Website
ppcenter.free.fr
I'm trying to use the Rhea ODE menu feature on Pseudo Saturn Kai release 20181227 installed on an action replay. But the Pseudo Saturn UI just locks up instead of showing the ODE menu. I have a genuine Rhea ODE and it is updated to the latest firmware (3.9.0). The SD card has three games on it. All three of the games work with the Rhea ODE just fine.

What am I doing wrong?
If Rmenu works fine, this may be a bug or something related to ODE being unsupported in Pseudo Saturn Kai.
First, do you confirm that Pseudo Saturn Kai is set up correctly for Rhea/Phoebe ? This requires "Optical Disc" in setting menu to be set to "Rhea/Phoebe".

And as indicated in PM, please send me the following files so that I can figure what is going wrong :
- Rhea.ini
- RMENU.ISO file from folder 01

Top
